PDL Series Dock Lifts

Presto PDL Series Loading Dock Scissor Lifts are the versatile solution for facilities that load and unload trucks with varying bed heights. When pit mounted they can access loads at grade level or any truck bed or dock height up to 67".

Deck platforms and throw-over plates feature a diamond-tread pattern for improved traction. Removable steel handrails keeps workers and loads safely on the lift.

Presto PDL Series Loading Dock Scissor Lifts can be either pit or pad mounted and can be configured in a variety of transfer arrangements.

Model Capacity Roll-Over
Capacity 		Lifting
Height 		Lowered
Height 		Standard
Platform (in) 		Max
Platform (in) 		Rise Time
Approx. 		Standard
Motor 		Cylinders Ship
Weight
Model : PDL-60-50
Capacity : 5,000 lbs.
Roll-Over
Capacity : 10,000
Lifting
Height : 67"
Lowered
Height : 8"
Standard
Platform (in) : 72 x 96
Max
Platform (in) : 96 x 120
Rise Time
Approx. : 27 sec.
Standard
Motor : 3.2 HP
Cylinders : 2
Ship
Weight: 2800 lbs.
Model : PDL-60-60
Capacity : 6,000 lbs.
Roll-Over
Capacity : 10,000
Lifting
Height : 67"
Lowered
Height : 8"
Standard
Platform (in) : 72 x 96
Max
Platform (in) : 96 x 120
Rise Time
Approx. : 27 sec.
Standard
Motor : 3.2 HP
Cylinders : 2
Ship
Weight: 2900 lbs.

Share this product

  • Choose 5,000 or 6,000 lb. capacity
  • Removable handrail / four safety chains with snap hooks
  • Corrosion resistant galvanized base and legs
  • Service any truck bed height
  • Access loading docks up to 67" hight
  • Designed for use with non-powered devices like pallet jacks
Download - General Catalog
